Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface

China Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface supplier
Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface supplier Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface supplier

Large Image :  Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface

Product Details:

Place of Origin: Hebei,China
Brand Name: JH Livestock Handling
Certification: ISO9001, CE
Model Number: Sheep Goat Yard Panels

Payment & Shipping Terms:

Minimum Order Quantity: 50 pieces
Packaging Details: Steel pallets
Delivery Time: 20 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 2000 pieces/month
Contact Now
Detailed Product Description
Features: Avoid Sheep Goat Bruising Type: Heavy, Medium, Light Duty
Ideal For: Sheep, Goat Yards Finish: Hot Dip Galvanized
Size: 0.45metres Width X 3.5metres Long X 1.0metres Height Material: Steel

Farm Ranch Used Portable Livestock Sheep Yard Panels And Gates





Our Sheep Panel is designed and constructed to the highest quality. Each panel is supplied with two pins for yard construction.

We have 3 kinds for your chose.



Sheep 3 Way Draft Race



Size: 0.45metres width x 3.5metres long x 1.0metres height

Vertical pipe: 40mm x 40mm with caps

Horizontal: 60mm x 30mm 6 oval rails

All galvanized steel used

Fully welded oval pipes,posts&brackets

Suppliers with pins



Premium Sheep Panel



1m High 3.1 Long (6 Rails) other lengths available

Posts:50x50x1.6mm pre-galvanized

6 Pcs of rails made by 60x30x1.6mm pre-galvanised oval pipe

Oval Rails/ Round Rails/ Square Rails

Fix Star Post Through Panel Posts At Pressure Points – An Ideal Option for where you would normally have Permanent Yards

Permanent or Semi-Permanent

Available in many different sizes

Available as a dorper panel-(extra height)



Heavy Duty Cattle Panel



High Visibility

115 X 42 Oval Rails

50 X 50 RHS Posts

Proven Coupling System With Heavy Duty Gal Pins

Heavily Galvanised

Feet on Bottom of the Panel

Available in 1600 High 5 Rail

Available in 1800 High 3200 Long 6 Rail

Also available in other sizes



Light Duty Round Pens



Diameter: 50' or 60'

Panels Dimensions: 12' x 6'

Gate Panel Dimensions: 6' x 9'

Gate Dimensions: 5.5' x 4.5' tall and swings both ways.

Number of Bars: 6

Gauge Bars: 19 Gauge, 1-11/16" Diameter Steel Tubing

Squared Welded Legs: 17.25" - 90° corner

Support: Extra strength with bent tubing, center support for bar strength.

Finish: Galvanized



Yard gate type



Cattle Yard 2.1m Gate In Bow/4.1m Double Gate In Bow

Sheep Gate U shape 2.2m/Semi-Permanent Sheep Gate



Surface treatment



hot-dipped galvanized or painted



Main market



Australia, New Zealand, South America, Europe.



Applications


Widely used in the farm/ranch for enclosure of livestock/animal(sheep/goats/cattle/horse etc) or protecting crops/vegetable. It also can be used as barrier fencing in car park area, or store fence.



The Effort Of The Sheep Yard Panels


• Protect your investment with our most reliable confinement for cattle, hogs and other large animals
• Able to withstand the demands of corralling large animal herds • Ideal for all terrains, as well as corrals and pastures
• Special wire crimps withstand even the most severe weather by allowing the fence to expand and contract

• Galvanized wire resists weathering as well as wear and tear book.



The Cattle Yard Panel Type



Rail Shape Length Height Rails Size Of Rail Pins
  mm mm   mm
Square 2200/2400 1000 6 40-40,25*25 2
Square 2200 1100 6 40*40 2
Oval 2200 1100 6 60*60 2
Square 2950 1100 6 40*40 2
Oval 2950 1100 6 60*60 2
Square 2400 1100 6 40*40 2
Oval 2400 1100 6 60*60 2
Other Size Can Be Offered As Wish



Specifications



  • Manufactured from Galvanized Steel
  • Robust construction
  • Available in lengths of 1.0m, 2.0m and 3.0m
  • Panels can be used in Permanent or Portable applications
  • Handy lugs for ground pinning
  • Wide top rail for operator comfort when leaning over or accessing yard to yard.
  • Lamb proof rail spacing
  • Height is 1000mm to discourage jumping



Additional Specifications



  • Materials

Pregalvanized Q195 - Q235 steel



  • Finishes



180g Cold Galvanised per m2





Full Yard Kits Available





Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface

Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface

The Blind Sheep Panels are designed to reduce distractions and improve the flow of stock.



Additional Specifications

  • Materials

Pregalvanized Q195 - Q235 steel

  • Finishes

120g Cold Galvanised per m2



Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface

Farm Cattle Yard Panels And Gates Galvanized / Painted Finish Surface
